Pusat Pemesinan CNC 500L
Metal Technics Polska MTP CNC 500L

Name: Metal Technics Polska MTP CNC 500L
Brand: Metal Technics Polska
Price: 20720 EUR
Availability: InStock

EXW harga tetap ditambah cukai perkhidmatan

€20,720

Tahun pembuatan

2025

Keadaan

Baharu (berfungsi sepenuhnya)

Lokasi

Sokołów Podlaski Poland

Pusat Pemesinan CNC 500L Metal Technics Polska MTP CNC 500L

Data mesin

Nama mesin:: Pusat Pemesinan CNC 500L

Pengeluar:: Metal Technics Polska

Model:: MTP CNC 500L

Tahun pembuatan:: 2025

Keadaan:: baharu

Fungsi:: berfungsi sepenuhnya

Harga & Lokasi

EXW harga tetap ditambah cukai perkhidmatan

€20,720

Lokasi:: Fabryczna 1, 08-300 Sokołów Podlaski, Polska

Hubungi

Butiran teknikal

Jumlah panjang:: 2,100 mm

Kelajuan spindel (min.):: 1 rpm

Kelajuan gelendong (maks.):: 8,000 rpm

Jumlah ketinggian:: 2,300 mm

Lebar keseluruhan:: 1,750 mm

Berat keseluruhan:: 2,600 kg

Panjang suapan paksi X:: 600 mm

Panjang suapan paksi Y:: 400 mm

Panjang hentakan paksi Z:: 450 mm

Kadar suapan paksi-X:: 18 m/min

Kadar suapan paksi Y:: 18 m/min

Kadar suapan paksi Z:: 16 m/min

Voltan masuk:: 400 V

Jenis arus masuk:: tiga fasa

Tempoh jaminan:: 12 bulan

Diameter pemasangan:: 120 mm

Jarak gerakan paksi X:: 600 mm

Jarak perjalanan paksi-Y:: 400 mm

Jarak gerakan paksi Z:: 450 mm

Kedudukan kepala pengisar:: pionowa

Laju pantas gandar Z:: 16 m/min

Gerakan pantas paksi X:: 18 m/min

Gerakan cepat paksi Y:: 18 m/min

Kelajuan putaran (maks.):: 8,000 rpm

Kelajuan putaran (min.):: 1 rpm

Panjang meja:: 800 mm

Beban meja:: 300 kg

Lebar meja:: 320 mm

Peralatan:: dokumentasi / manual, kelajuan putaran boleh diubah tanpa had

Butiran tawaran

ID iklan:: A21814638

Kemas kini:: terakhir pada 27.05.2026

Penerangan

The CNC 500L machining center is a modern and compact CNC milling machine designed for precise machining of metals and engineering plastics. Thanks to its rigid machine structure and linear guideways, it ensures high stability and accuracy even during intensive operation. The efficient spindle with a power of 5.5 / 7.5 kW and speeds up to 8000 rpm guarantees effective cutting performance across a wide range of materials.

The machine is equipped with an automatic tool changer (12 positions), significantly increasing productivity and reducing setup time. Its intuitive CNC control system allows for quick programming and easy operation, even when working with complex parts. High positioning accuracy and repeatability of ±0.02 mm make the CNC-500L ideal for both single-piece and batch production.

Additional features such as through-spindle coolant, chip evacuation system, chip conveyor, and a fully enclosed housing with LED lighting improve operator comfort and safety. Compact dimensions and the option to expand with a 4th and 5th axis make this machine a versatile solution for modern workshops.

Technical Specifications
Parameter Value
X-axis travel 600 mm
Y-axis travel 400 mm
Z-axis travel 450 mm
Distance from guideway to spindle center 100 – 550 mm
Table size 800 × 320 mm
T-slots 3 × 16 × 75 mm
Spindle speed up to 8000 rpm
Spindle power 5.5 / 7.5 kW
Spindle taper BT40 (Ø120)
Linear guideways 30 mm
Rapid feed X/Y/Z 18 / 18 / 16 m/min
Cutting feed rate 1 – 8000 mm/min
Positioning accuracy ±0.02 mm
Repeatability ±0.02 mm
Tool magazine capacity 12 tools
Max. table load 300 kg
Total power 15 kVA
Dimensions 2100 × 1750 × 2300 mm
Weight 2600 kg
Power supply three-phase
Equipment and Options
Automatic tool changer (ATC) – 12 positions
Through-spindle coolant system
Chip evacuation system and chip conveyor
Nsdpfx Ajy H Dnrsfqjwg
Full enclosure with LED lighting
UPS backup power supply for control system
Option for 4th and 5th rotary axis

This machining center combines precision, performance, and compact design, making it a reliable and efficient solution for a wide range of machining applications.
