IMA BIMA 300
IMA BIMA 300

Tahun pembuatan

2005

Keadaan

Terpakai

Lokasi

Poland

Data asas

Nama mesin:: IMA BIMA 300

Pengeluar:: IMA

Model:: BIMA 300

Tahun pembuatan:: 2005

Keadaan:: sedia untuk digunakan (terpakai)

Harga & Lokasi

Lokasi:: , Poland

Hubungi

Butiran teknikal

Dimensi dan berat

Berat keseluruhan:

6,000 kg

Lebar keseluruhan:

3,830 mm

Spindel

Kuasa motor gelendong:

7,500 W

Kelajuan gelendong (maks.):

18,000 rpm

Bahan/produk boleh diproses

Panjang produk (maks.):

5,750 mm

Maklumat lanjut

Bilangan gandar:

Butiran tawaran

ID iklan:: A23192771

Nombor rujukan:: PL-CNC-IMA-2005-00002

Kemas kini:: terakhir pada 23.10.2026

Penerangan

This 4-axis IMA BIMA 300 CNC Wood Machining Centre was manufactured in 2005. It features an impressive X-axis machining range of 4300 mm and a Y-axis machining range of 1400 mm. The spindle power is 7.5 kW with a maximum speed of 18,000 rpm. If you are looking to get high-quality wood machining capabilities, consider the IMA BIMA 300 machine we have for sale. Contact us for further details.

Working area
• X-axis machining range: 4300 mm (4600 mm per manual; to be confirmed)
• Y-axis machining range with main spindle and Ø20 mm tool: 1400 mm
• Y-axis machining range with drilling unit (all vertical spindles): 1100 mm
• Maximum workpiece height above vacuum cup surface: 125 mm
• Maximum workpiece thickness: Depending on equipment and application
• Working height: approx. 950 mm
• Two-zone working area without pendulum machining: 2 × 2050 mm; central clearance: 200 mm
• Two-zone working area with pendulum machining: 2 × 1750 mm; central clearance: 800 mmMain spindle
• Tool interface: HSK-F63
• Taper diameter: 38 mm
• Automatic tool clamping (clamping force: 11,000 N; unclamping force: 20,400 N)
• Maximum tool weight: 6 kg
• Rotation direction: Programmable CW/CCW
• Drive: Three-phase motor with frequency inverter
• Lubrication: Factory-lubricated
• Cooling: Air-cooled
Laedpfxo Ad Hhdj Acfsh
• Integrated CNC-controlled rotary axis for aggregate positioning through 360°, with torque support and pneumatic connectionAxis speeds
• Rapid traverse X/Y: 60 m/min
• Rapid traverse Z: 30 m/minVacuum, extraction and compressed air
• Required compressed air pressure: 7 bar
• Extraction connection diameter: 250 mm
• Required extraction air velocity: 28 m/s
• Required extraction airflow: 4,950 m³/h
• Vacuum pump capacity: 90 m³/h

Additional equipment

• 90° angle drilling aggregate
• 3x HSK tool holders
