Pusat Pemesinan Mendatar CNC Homag Profi BOF 722/58/16/KC 2008

Homag Profi BOF 722/58/16/KC

Colour: White
Empty weight: 9.000 kg
Price: On request


- Details:


- └ Description: Includes the input/output system


- Year: 2008
- Documentation available: Yes


- └ Type Documentation: Technical data, Operating system, Electrical diagrams, Maintenance history, Assembly manual, Parts book, User manual
- └ Language: NL
- └ Type: Hardcopy


- CE marking present: Yes
- CE certificate present: No
- Serial number:
- Number of milling spindles [pcs.]: 2


- └ Milling spindle 1:


- - Number of controlled axes [pcs.]: 4
- - Max. spindle speed [rpm]: 30000
- - C-axis present: Yes


- └ Milling spindle 2:


- - Number of controlled axes [pcs.]: 4
- - Max. spindle speed [rpm]: 30000
- - C-axis present: Yes




- Type milling table: Beam table
- Tool holder: HSK-F63
- Material clamp system: Pneumatic
- Tool changer positions [pcs.]: 36
- System/software: WoodWOP
- Safety feature: Enclosed fence, Door interlock switches, Safety light curtain
- Vacuum pump present: Yes


- └ Number [pcs.]: 2
- └ Brand: Elmo Rietschle
- └ Type: 2BL2141
- └ Connection diameter [mm]: 50
Nlodpfjzhr Rzjx Akkef


- Tools included: Yes
- CNC options: Loading system, Label machine, Manual control, Unloading system, Offcut conveyor
- CNC documentation available: USB stick
- Table length [mm]: 2500
- Table width [mm]: 1500
- Working range X [mm]: 5800
- Working range Y [mm]: 1600
- Z-axis working range [mm]: 535
- Voltage [V]: 400
- Current consumption [A]: 91
- Installed length [mm]: 12200
- Installed width [mm]: 9000
- Installed height [mm]: 3500
- Transport weight [kg]: 9000kg
- Transport packages [pcs.]: 8
