Mesin penggulung semula gulungan keluli

Foldsolutions SVM-100

For sale: lightly used sheet metal rewinding machine SVM-100, designed for automatic rewinding of sheet metal from large coil rolls into smaller rolls of 25m2 (1250*20,000 mm).

The machine was manufactured in 2024, has been used very little, is in excellent technical and visual condition, and is fully ready for operation. It is an excellent solution for companies that produce roofing materials or other sheet metal products supplied in rolls.

The machine automatically:
- Unwinds the sheet metal from the coil up to 1 ton. If you want to rewind from 2-5 ton coils, an automatic unwinding unit is required to feed the sheet metal.
- Winds the sheet metal into a roll.
- Cuts the sheet to a specified length.
- Allows the roll to be wrapped with stretch film.
- Applies protective film to the surface of the sheet metal.

The machine is connected – it can be inspected and tested.

Technical specifications:
Chjdpfxozibwge Aa Heb
Manufacturer: Foldsolutions / UAB Pakservisas
Model: SVM-100
Year of manufacture: 2024
Made in: Lithuania

Operating parameters:
Sheet metal width: 1230–1260 mm
Sheet metal thickness: 0.4–0.6 mm
Maximum roll length: 20 m
Roll diameter: approx. 300 mm

Equipment:
Automatic sheet metal winding
Sheet metal cutting to a specified length
Automatic roll packing process with stretch film
Option to use protective film on the sheet metal
Integrated length measuring encoder
Touchscreen control panel
Manual and automatic operating modes
Pneumatic cutting system
Adjustable operating speeds
Length calibration function for precise production
Emergency stop system

Technical data:
Electrical power: 400 V / 50 Hz / 3 phases
Power: 2.6 kW
Required compressed air pressure: 0.65 MPa
Air consumption: 0.3 m³/min
Dimensions (L × W × H): 2555 × 1730 × 1800 mm
Weight: approx. 600 kg

Application:
Ideally suited for roofing materials, facade, sheet metal products, sheet metal processing companies, and other manufacturers who require fast, accurate, and safe preparation of sheet metal rolls for transport or storage.

If you have any further questions, we will be happy to answer them.
